Mondraker F-Podium Carbon DC 2023 Down Country Bike

Available with Mondaraker Spain in the sizes shown above. Expect delivery within 8-9 working days of placing an order.

The Down Country concept which has prevailed in recent years on World Cup tracks has led us to present the DC version of the F-Podium.

As the evolution of these tracks has seen them getting more technical and more demanding we’ve responded by increasing the rear wheel travel to 115mm to keep things firmly under control.

It comes as no surprise then that this is the bike our PMG Racing Team competes with in the majority of international competitions.

At the same time agile, light and rigid, it allows you to push yourself to the limit and take advantage of every single watt you put through the pedals.

It’s the bike of choice of the PMX Racing Team World Cup riders, which says it all really.

Specification

Frame	F-Podium 29 Stealth Air Full Carbon, XCO Optimized Zero Suspension System, 115mm, XC Forward Geometry, Carbon Monoblock upper link, BSA bottom bracket, tapered head tube, HHG internal cable routing, dedicated 1X drivetrain design, Boost 12×148mm rear axle, shock mudguard, postmount rear brake mount.
Rear Shock	Rockshox SID Select+ RLR Debonair, 185×50mm. Settings: OneLock 2 position remote compression (open/lock), low-speed rebound, air preload. Trunnion top mount, 22.2×10mm bottom bushings
Shock Settings	Light compression, medium rebound, Lockout 430, 1 Token
Fork	Rockshox SID Select RL 29, 120mm, Charger, Debonair, tapered steerer tube, Boost 15×110mm axle, 35mm tapered aluminum stanchions, offset 44mm. Settings: OneLock 2 position remote compression (open/lock), low-speed rebound, air preload
Headset	Acros AZX-239 R1 Block Lock, ZS44/28.6 top, ZS56/40 bottom
Fork Remote	RockShox OneLoc
Stem	MDK, 6061 T6 Alloy, 31.8mm barbore, rise: +/-5°, length: sizes S/M: 50mm, size L: 60mm, size XL: 70mm
Handlebar	Onoff Sulfur 0.2, double butted 6061 alloy, rise: 4.8mm, width: 760mm, 9° backsweep, 0° upsweep, 31.8mm barbore
Grips	Onoff Twin, 1lock-on, 135mm
Seatpost	Onoff Pija dropper internal, diameter 31.6mm, S size: 405×95-125mm, M size 458×120-150mm, L size: 498×140-170mm, XL size: 498×140-170mm
Saddle	Fizik Antares R7
Front Brake	SRAM Level T, 2 piece caliper, Centerline 180mm IS 6 bolts one-piece rotor, steel-backed organic pad
Rear brake	SRAM Level T, 2 piece caliper, Centerline 160mm IS 6 bolts one-piece rotor, steel-backed organic pad
Rims	Mavic Crossmax 29, 25mm internal width, welded rim, hookless, tubeless ready, 24 spokes
Spokes	Mavic straightpull duble butted, contactless lacing
Front Hub	Mavic, Boost 15×110mm, IS 6 bolts
Rear Hub	Mavic, Boost 12×148mm, ID360 Ratched system, IS 6 bolts, XD freehub
Front Tyre	Maxxis Rekon Race 29×2.4, EXO protection, tubeless ready, 120TPI, folding bead
Rear Tyre	Maxxis Rekon Race 29×2.4, EXO protection, tubeless ready, 120TPI, folding bead
Crankset	Truvativ Stylo 6K Eagle, 12s, Boost, DUB axle, Direct Mount chain ring, S size: 170mm, M/L/XL size: 175mm
Chainring	34T, steel, X-Sync 2
Bottom Bracket	SRAM DUB BSA, sealed bearings, 73mm
Chain	SRAM SX Eagle, 12s, Powerlock
Rear Derrailleur	SRAM GX Eagle, Type 3 roller bearing clutch, cage lock, 1×12s, X-Actuation 1:1
Shifter	SRAM Trigger SX Eagle, 12s, X-Actuation 1:1
Cassette	SRAM XG-1230, 11-50T, 12s
Derailleur Hanger	SRAM UDH
Max System Weight	120kg – The maximum system weight is the maximum total weight of the bike, rider and any luggage combined

Specifications are subject to change without notice

Size Guide

Frame Size	Minimum Height	Maximum Height
S	165cm (5’5”)	170cm (5’7”)
M	170cm (5’7”)	180cm (5’11”)
L	175cm (5’9”)	187cm (6’1”)
XL	185cm (6’1”)	195cm (6’5”)

We have developed our size guide from our selling experience and it may differ from the manufacturers guide. Please note, this is only a guide and if you have any concerns over sizing please get in contact

Geometry

Frame Size	S	M	L	XL
A – Seattube Length	390 mm	420 mm	470 mm	510 mm
B – Toptube Length	583 mm	603mm	629 mm	654 mm
C – Bottom Bracket Drop	-31	-31	-31	-31
D – Bottom Bracket Height	337 mm	337 mm	337 mm	337 mm
E – Chainstay Length	432 mm	432 mm	432 mm	432 mm
F – Seat Tube Angle	70.8°	70.8°	70.8°	70.8°
G – Effective Seattube Angle	75.1°	75.1°	75.1°	75.1°
H – Headtube Angle	66.8°	66.8°	66.8°	66.8°
I – Fork Offset	44 mm	44 mm	44 mm	44 mm
J – Wheelbase	1146 mm	1167 mm	1191 mm	1217 mm
K – Headtube Length	85 mm	90 mm	100 mm	115 mm
L – Reach	430 mm	450 mm	470 mm	490 mm
M – Stack	577 mm	582 mm	591 mm	605 mm

Want to compare the size of your current bike to this one? Read our Reach and Stack guide here.
