Marin Sausalito E1 ST 2026 Grey eBike
The power to move through the urban landscape cleanly and efficiently is now as simple as pedaling
10% of free accessories
Get 10% of free accessories when you
Excludes discounted bikes, ex-demo bikes and Cyclescheme.
We have done our best to sufficiently estimate demand. Please contact us if you have a question or wish to check availability.
Related Products
Details
The power to move through the urban landscape cleanly and efficiently is now as simple as pedaling.
The Sausalito family of bikes helps you keep up the pace with a fun and lively assist to flatten hills and get you from A to B with a fresh smile, as well as clean clothes and a smart look.
Commuting
Cruising
Multi-surface exploring
Specification
| Frame | Series 3 Butted and Formed 6061 Aluminum, 650B Wheel, Forged Motor Mount, Hydroformed Downtube Battery Mount, Integrated Wiring, Internal Housing, Kickstand, Rack, and Fender Mounts |
| Fork | Steel, Moto Blade, Disc Specific, Fender and Rack Eyelets |
| Rims | Marin Aluminum Double Wall, Disc Specific |
| Rear Hub | Forged Alloy, Disc Specific, 32H |
| Front Hub | Forged Alloy, Disc Specific, 32H |
| Spokes | 14g Black Stainless Steel |
| Tyres | WTB Horizon, 650Bx47, Wire Bead |
| Derailleur | Shimano CUES 9-Speed |
| Shifter | Shimano CUES 9-Speed |
| Crankset | Forged Aluminum w/ 38T Steel Chairing |
| Motor | Bosch Active Plus, 250W, 50Nm |
| Battery | Bosch PowerPack 545, 545Wh |
| Charger | Bosch 2A Smart system Charger |
| Remote/Display | Bosch Purion 200 |
| Chain | KMC E11S |
| Cassette | Shimano CUES 9-Speed 11-46T |
| Front Brake | Tektro HD-M275 Hydraulic, 180mm Rotor |
| Rear Brake | Tektro HD-M275 Hydraulic, 180mm Rotor |
| Brake Levers | Tektro Hydraulic |
| Handlebar | Marin Mini Riser Alloy |
| Stem | Marin Alloy |
| Grips | Marin Country |
| Headset | FSA No. 57E |
| Seatpost | Marin Alloy, 30.9mm |
| Saddle | Marin City Plush |
| Pedals | Flat |
| Kickstand | Rear Mount Alloy |
| Fenders | Extruded Aluminum Alloy Fenders w/ Stainless Steel Hardware |
Specifications are subject to change without notice
Size Guide
| Frame Size | Minimum Height | Maximum Height |
| Small | 153cm (5’0”) | 163cm (5’4”) |
| Medium | 163cm (5’4”) | 173cm (5’8”) |
| Large | 173cm (5’8”) | 180cm (5’11”) |
Geometry
| Frame Size | Small | Medium | Large |
| A – Stack | 590 | 617.7 | 645.8 |
| B – Reach | 380 | 405 | 425 |
| C – Headtube Angle | 69.5° | 69.5° | 69.5° |
| D – Headtube Length | 120 | 150 | 180 |
| E – Seattube Angle | 74° | 74° | 74° |
| F – Seattube Length | 430 | 480 | 520 |
| G – Toptube Effective | 549 | 582 | 610.2 |
| H – BB Height | 296.5 | 296.5 | 296.5 |
| I – BB Drop | 45 | 45 | 45 |
| J – Chainstay | 455 | 455 | 455 |
| K – Wheelbase | 1083.4 | 1118.9 | 1149.4 |
| L – Standover Height | 460.19 | 487.35 | 510.57 |
| M – Fork Offset | 44 | 44 | 44 |
| Seatpost Diameter | 27.2 | 27.2 | 27.2 |
| Handlebar Width | 720 | 740 | 740 |
| Stem Length | 45 | 45 | 45 |
| Crank Length | 170 | 170 | 175 |
Want to compare the size of your current bike to this one? Read our Reach and Stack guide here.
