Marin Rift Zone 27.5 1 2023 Black/Orange Trail Bike
The Rift Zone 27.5 is our most playful trail bike, made for the rider that catches a bit of air off of every root in the trail, is always looking for an alternate line, and ends every ride with a smile.
10% of free accessories
Get 10% of free accessories when you
Excludes discounted bikes, ex-demo bikes and Cyclescheme.
We have done our best to sufficiently estimate demand. Please contact us if you have a question or wish to check availability.
-
Cube Stereo Hybrid One55 C:68X SLT 2024 Prizm/Silver eMTB
Starting at: £6,998.99
-
Cannondale Moterra Neo 3 2024 Teal eMTB
Starting at: £3,598.99
-
Hope Tech V4 Brake Pads Sintered
£20.00
Related Products
Details
The Rift Zone 27.5 is our most playful trail bike, made for the rider that catches a bit of air off of every root in the trail, is always looking for an alternate line, and ends every ride with a smile.
This is an all-around suspension bike with trail performance far out stretching the asking price.
All around trail enjoyment
Having fun
Specification
| Frame | Series 3 6061 Aluminum Frame, 27.5” Wheels, 120mm Travel, MultiTrac Suspension Platform, 141 Boost Spacing (upgradable to 148×12), 73mm Threaded BB w/ ISCG05 Tabs |
| Front Suspension | RockShox Recon Silver RL 27.5”, 130mm Travel, Solo Air, Compression and Rebound Adjustment, Alloy Tapered Steerer, Fast Black Uppers, 110×15mm Boost Spacing, Maxle Stealth, 37mm Offset |
| Rear Suspension | X-Fusion O2 Pro R, Custom Tune, 210×50mm, M8x25mm Hardware Top and Bottom |
| Rims | Marin, Double Wall Alloy, 29mm Inner, Pinned Joint, Disc Specific, 32H, Tubeless Compatible |
| Rear Hub | Shimano HB-MT200B, 141 QR, Centerlock, Standard Freehub Body |
| Front Hub | Shimano HF-MT400B, 110×15mm, Centerlock |
| Spokes | 14g Black Stainless Steel |
| Tires | Vee Tire Crown Gem 27.5×2.3”, Dual Control Compound, Tubeless Ready |
| Rear Derailleur | Shimano Deore, 11 Speed, SGS |
| Shimano Deore, 11-Speed, SL-5100R | |
| Crankset | Marin Forged Alloy, Integrated Steel 32T Narrow Wide Chainring, Boost Spacing |
| Bottom Bracket | External Sealed Cartridge Bearing |
| Chain | KMC X-11 Silver and Black |
| Cassette | SunRace, 12-Speed, 11-51T, ED Black |
| Front Brake | Shimano BR-MT201 Hydraulic Disc, 180mm Rotor |
| Rear Brake | Shimano BR-MT201 Hydraulic Disc, 180mm Rotor |
| Brake Levers | Shimano BR-MT201 Hydraulic Disc |
| Handlebar | Marin Mini-Riser, 6061 Double Butted Aluminum, 780mm Width, 28mm Rise, 5º Up, 9º Back |
| Stem | Marin 3D Forged Alloy, 35mm |
| Grips | Marin MTN, Closed End |
| Headset | FSA No 57E, Semi-Sealed Cartridge Bearings, 1 1/8” × 1 1/2” |
| Seatpost | Marin Alloy, 30.9mm |
| Saddle | Marin Speed Concept |
| Pedals | Not included |
| Extras | Closed 9-12 Thru-Axle QR System |
Specifications are subject to change without notice
Size Guide
| Frame Size | Minimum Height | Maximum Height |
| X Small | 155cm (5’1”) | 163cm (5’4”) |
| Small | 163cm (5’4”) | 170cm (5’7”) |
| Medium | 170cm (5’7”) | 178cm (5’10”) |
| Large | 178cm (5’10”) | 185cm (6’1”) |
| X Large | 185cm (6’1”) | 196cm (6’5”) |
We have developed our size guide from our selling experience and it may differ from the manufacturers guide. Please note, this is only a guide and if you have any concerns over sizing please get in contact
Geometry
| Frame Size | XS | S | M | L | XL |
| A – Stack | 579 | 583.6 | 588.2 | 597.3 | 601.9 |
| B – Reach | 410 | 425 | 445 | 465 | 485 |
| C – Headtube Angle | 66.5° | 66.5° | 66.5° | 66.5° | 66.5° |
| D – Headtube Length | 105 | 110 | 120 | 125 | 130 |
| E – Seattube Angle | 75° | 74.7° | 74.5° | 74.3° | 74.1° |
| F – Seattube Length | 330 | 380 | 425 | 470 | 515 |
| G – Toptube Effective | 570.6 | 586.8 | 608.1 | 632.9 | 651.9 |
| H – BB Height | 338.5 | 338.5 | 338.5 | 338.5 | 338.5 |
| I – BB Drop | 18 | 18 | 18 | 18 | 18 |
| J – Chainstay | 430 | 430 | 430 | 430 | 430 |
| K – Wheelbase | 1129.4 | 1146.3 | 1168.3 | 1192.3 | 1214.3 |
| L – Standover Height | 647 | 665 | 702 | 727 | 768 |
| M – Fork Offset | 42 | 42 | 42 | 42 | 42 |
| Seatpost Diameter | 30.9 | 30.9 | 30.9 | 30.9 | 30.9 |
| Handlebar Width | 780 | 780 | 780 | 780 | 780 |
| Stem Length | 35 | 35 | 35 | 35 | 35 |
| Crank Length | 170 | 170 | 175 | 175 | 175 |
Want to compare the size of your current bike to this one? Read our Reach and Stack guide here.
Additional Information
| Manufacturer | Marin |
|---|---|
| RRP | No |
