Cube Stereo One77 Race 2022 Desert/Grey Enduro Bike
The Stereo ONE77 Race's precise handling and boulder-swallowing suspension performance starts with the plush, accurate RockShox Zeb Ultimate fork and Super Deluxe Ultimate shock.
10% of free accessories
Get 10% of free accessories when you
Excludes discounted bikes, ex-demo bikes and Cyclescheme.
We have done our best to sufficiently estimate demand. Please contact us if you have a question or wish to check availability.
-
Shimano EC-E6000 STEPS Battery Charger
£154.99 -
Hope Tech V4 Brake Pads Sintered
£20.00 -
Madison Zenith Men's Long Sleeve Jersey Olive
Starting at: £44.99
Details
Those people who say you can’t have it all? They’re wrong. The Stereo ONE77 Race’s precise handling and boulder-swallowing suspension performance starts with the plush, accurate RockShox Zeb Ultimate fork and Super Deluxe Ultimate shock. Mountain-taming ability is added with Shimano’s peerlessly reliable XT 1×12 gears and a Race Face Turbine crank.
Matching Shimano XT hydraulic disc brakes with Newmen Evolution wheels wrapped with grippy Maxxis Assegai and Minion DHR II tyres ensure you’re always in full control. And there’s a remote dropper post, too, so you can show the mountain who’s boss.Specification
| Frame | HPA Advanced Hydroform, ATG, ETC 4-Link, Air/Coil Shock Mount Flip-Chip, ISCG Mount, AXH |
| Fork | RockShox ZEB Ultimate RC2, 110×15mm, Tapered, 170mm |
| Shock | RockShox Super Deluxe Ultimate, 230×65mm, Rebound & Low Speed Compression Adjust w/ 2-Position Lever |
| Shock Hardware | Top: 40×8mm, Bottom: 20×8mm |
| Brake System | Shimano XT BR-M8120, Hydr. Disc Brake (203/180) |
| Rear Derailleur | Shimano XT RD-M8100-SGS, ShadowPlus, 12-Speed |
| Shifter | Shimano XT SL-M8100-IR, Direct Attach |
| Crankset | Race Face Turbine, 30T, 170mm |
| Chain Guide | MRP SXg Chain Guide |
| Cassette | Shimano XT CS-M8100, 10-51T |
| Chain | Shimano CN-M6100 |
| Wheelset | Newmen Evolution SL A.30, 28/28 Spokes, 15×110mm/12×148mm, |
| Front Tyre | Maxxis Assegai, MaxxGrip/EXO+, Tubeless Ready, 2.5 WT |
| Rear Tyre | Maxxis Minion DHR II, MaxxTerra/EXO+, Tubeless Ready, 2.4 WT |
| Stem | Race Face Turbine R 35 |
| Handlebar | Race Face Turbine R 35, 800mm |
| Grips | SDG Thrice |
| Seat Post | CUBE Dropper Post, Handlebar Lever, Internal Cable Routing, 31.6mm, 150mm |
| Seat Clamp | CUBE Screwlock, 34.9mm |
| Saddle | SDG Bel Air V3 |
| Headset | ACROS Integrated, Top 1 1/8”, Bottom 1 1/2”, Fiber Inserts for 0.6° Angle Adjustment |
| Weight | 15.4kg |
Specifications are subject to change without notice
Size Guide
| Frame Size | Minimum Height | Maximum Height |
| Medium | 171cm (5’6”) | 177cm (5’9”) |
| Large | 177cm (5’9”) | 183cm (6’0”) |
| X Large | 183cm (6’0”) | 189cm (6’2”) |
| XX Large | 189cm (6’2”) | 195cm (6’5”) |
We have developed our size guide from our selling experience and it may differ from the manufacturers guide. Please note, this is only a guide and if you have any concerns over sizing please get in contact
Geometry
| Frame Size | M | L | XL | XXL |
| Seat Tube | 420 – 420 | 420 – 420 | 470 – 470 | 470 – 470 |
| Top Tube Horizontal | 583.22 – 584.77 | 603.7 – 605.27 | 626.92 – 628.58 | 656.38 – 655.2 |
| Seat Angle | 76.71 – 76.5 | 76.71 – 76.5 | 76.7 – 76.5 | 76.7 – 76.5 |
| Head Tube Angle | 63.8 – 64.4 | 63.8 – 64.4 | 63.8 – 64.4 | 63.8 – 64.4 |
| Chainstays | 434.5 – 434.5 | 434.5 – 434.5 | 434.5 – 434.5 | 434.5 – 434.5 |
| Head Tube | 103 – 103 | 104.5 – 104.5 | 114.5 – 114.5 | 134.5 – 134.5 |
| Wheelbase | 1223.42 – 1215.56 | 1244.03 – 1236.21 | 1268.41 – 1260.56 | 1297.22 – 1289.26 |
| BB-Height to Hub | 26.6 – 25 | 26.57 – 25 | 26.54 – 25 | 25 |
| Reach | 445.99 – 444.33 | 471.94 – 464.33 | 485.9 – 484.36 | 505.88 – 504.42 |
| Stack | 625.52 – 627.49 | 626.83 – 628.84 | 635.78 – 637.86 | 655.71 – 655.89 |
| Seatpost Length | 480 | 480 | 480 | 480 |
| Seatpost Diameter | 31.6 | 31.6 | 31.6 | 31.6 |
| Stem Angle | 6 | 6 | 6 | 6 |
| Crank Length | 170 | 170 | 170 | 170 |
| Stem Length | 40 | 40 | 50 | 50 |
| Handlebar Width | 780 | 780 | 780 | 780 |
| Seatpost Drop | 150 | 150 | 150 | 150 |
Want to compare the size of your current bike to this one? Read our Reach and Stack guide here.
Additional Information
| Manufacturer | Cube |
|---|---|
| RRP | N/A |
