Cube Stereo Hybrid One55 C:68X TM 2024 Olive/Chrome eMTB

Large and X Large in stock now! Delivery in 2-3 working days. Other sizes shown available with Cube. Expect delivery within 8-9 working days of placing an order.

Light weight. Speed. Integration. These are the defining qualities of the new Stereo Hybrid ONE55 C:68X, which makes use of up to six different fibre types to meet the specific demands of each part of the frame. The result is a chassis that’s the lightest e-mtb intube frame we’ve ever built – up to 20% lighter compared to our Stereo Hybrid 140 frame – combined with best-ever stiffness and, as you’d expect, a superior ride.

An adjustable head angle and longer reach contribute to handling that more confident riders will love, serving up a cut-and-paste feel that enables tricky line choices even at speed thanks to 150mm of progressive rear wheel travel.

Full internal cable routing reduces clutter and maintenance, and Bosch’s new controller is neatly housed inside the top tube and can be controlled via Bluetooth from the optional remote. It’s the complete package.

Less is more, except when more is more. Confused? Don’t be. The new Stereo Hybrid ONE55 C:68X TM 750 29 has our lightest-ever hybrid full-suspension intube frame, thanks to advanced C:68X® carbon technology.

But its agile geometry, combined with a 160mm Fox 38 Factory Grip2 fork up front and Float X2 Factory shock at the rear, is also designed to take on any alpine descent, at any speed.

A 750Wh battery, integrated Bosch System controller and fourth-generation Bosch CX drive unit with up to 85Nm of torque work seamlessly with Shimano’s legendary XT 1×12 transmission to make light work of whatever route you’ve chosen for the day. Keeping it all under control is a pair of Shimano XT hydraulic disc brakes with 203mm rotors front and rear.

And a Newmen Evolution wheelset, Maxxis Assegai 2.5in and Minion DHR II 2.4in tyres and a remote dropper post ensure you’ll always have the rubber side down on the trail, where it should be.

Specification

Frame	C:68X® Monocoque Advanced Twin Mold Technology, Efficient Trail Control, FSP 4-Link, Agile Trail Geometry, Boost 148, UDH™, Fully Integrated Battery, Advanced Internal Cable Routing
Wheels Size	29”
Fork	Fox 38 Float Factory FIT GRIP2, Tapered, 15×110mm, E-Bike Tune, 160mm, Kashima Coated
Shock	Fox Float X2 Factory, 230×60mm, High/Low Speed Rebound & Compression w/ 2-Position Lever, Kashima Coated
Shock Hardware	Front: 30×8mm, Rear: DU-Bushing 12,7mm
Drive Unit	Bosch Drive Unit Performance CX Generation 4 (85Nm) Cruise (250Watt), Smart System
Remote	Bosch Wireless Mini Remote
Display	Bosch Top Tube System Control
Battery	Bosch PowerTube 750Wh Smart System (battery weight 4.3kg)
Charger	Bosch 4A Smart System (2.3h 50% – 6h 100%)
Brake System	Shimano XT BR-M8120, Hydr. Disc Brake (203/203)
Rear Derailleur	Shimano XT RD-M8100-SGS, ShadowPlus, 12-Speed
Shifter	Shimano XT SL-M8100-IR, Direct Attach
Crankset	e*thirteen Plus Crank, 34T, 165mm
Chain Guide	Reverse Flip-Guide E-Chain Guide, Direct Mount, GEN4
Cassette	Shimano XT CS-M8100, 10-51T
Chain	Shimano CN-M8100
Wheelset	Newmen Evolution SL E.G. 30, 28/28 Spokes, 15×110mm/12×148mm, Tubeless Ready
Front Tyre	Maxxis Assegai, MaxxGrip/EXO+, Tubeless Ready, 2.5 WT
Rear Tyre	Maxxis Minion DHR II, MaxxGrip/DoubleDown, Tubeless Ready, 2.4 WT
Stem	Race Face Turbine R 35
Handlebar	Race Face Turbine R 35, 800mm
Grips	ACID Disrupt, Soft Compound
Seat Post	Fox Transfer Factory 31.6mm, Kashima Coated
Seatclamp	Cube Screwlock Semi Integrated, 34.9mm
Saddle	Natural Fit Venec
Headset	ACROS AZF-675, ICR (Integrated Cable Routing), Top Zero-Stack 1 1/2” (ZS 56mm), Bottom Zero-Stack 1 1/2” (ZS 56mm), Fiber Inserts for Angle Adjustment
Quoted Weight	22.90kg
Maximum Rider/Bike Weight	135kg – The weight includes the bike and the rider incl. clothing, as well as any equipment that may be on the rider’s body (e.g. backpack) and must not be exceeded.
Max System Weight	135kg – The maximum system weight is the maximum total weight of the bike, rider and any luggage combined

Specifications are subject to change without notice

Size Guide

Frame Size	Minimum Height	Maximum Height
Medium (29” Wheels)	168cm (5’6”)	175cm (5’9”)
Large (29” Wheels)	175cm (5’9”)	183cm (6’0”)
X Large (29” Wheels)	183cm (6’0”)	191cm (6’3”)

We have developed our size guide from our selling experience and it may differ from the manufacturers guide. Please note, this is only a guide and if you have any concerns over sizing please get in contact

Geometry

Frame Size	M 29	L 29	XL 29
Seat Tube	405	420	470
Top Tube Horizontal	599 / 601	626 / 629	657 / 659
Seat Angle	75.7° / 75.5°	75.7° / 75.5°	75.7° / 75.5°
Head Tube Angle	64.4° / 65°	64.4° / 65°	64.4° / 65°
Chainstay	454	454	454
Head Tube	105	115	135
Wheelbase	1234 / 1226	1263 / 1255	1295 / 1287
BB-Height to Hub	32 / 30	32 / 30	32 / 30
Reach	449 / 447	474 / 472	497 / 495
Stack	624 / 629	633 / 635	651 / 653
Seatpost Length	445	485	485
Seatpost Diameter	32	32	32
Stem Angle	6°	6°	6°
Crank Length	165	165	165
Stem Length	40	40	40
Handlebar Width	780	780	780
Seatpost Stroke	150	170	170
Rear Suspension Travel	150	150	150

Want to compare the size of your current bike to this one? Read our Reach and Stack guide here.
