Cube Stereo Hybrid 140 HPC Action Team 27.5 2022 Small eMTB
Cube Stereo Hybrid 140 HPC Action Team 27.5 2022 Small eMTB
10% of free accessories
Get 10% of free accessories when you
Excludes discounted bikes, ex-demo bikes and Cyclescheme.
We have done our best to sufficiently estimate demand. Please contact us if you have a question or wish to check availability.
Details
Looking for bigger frame sizes of this bike? Click here.
Please note shown image is not correct.
Small but perfectly formed, the Stereo Hybrid 140 HPC Actionteam 625 defines all-mountain e-mtb performance. Four-piston Shimano XT brake calipers harness the incredible grip of Schwalbe’s Magic Mary SuperTrail and Big Betty SuperGravity 2.4in tyres to provide powerful speed control, no matter the conditions.
Shimano XT 1×12 gears deliver the combined power of the fourth-generation Bosch CX drive unit and your pedalling to the Newmen Evolution wheelset, backed up by a 625Wh battery. And with a Fox 36 Float Factory fork, Float X Factory shock and remote dropper post, you’ll soon discover that winning feeling out on the trail.
Specification
| Frame | C:62 Monocoque Advanced Twin Mold Technology, Aluminium 6061 T6 Rear Triangle, Efficient Trail Control, FSP 4-Link, Agile Trail Geometry, Boost 148, Full Integrated Battery, Advanced Internal Cable Routing |
| Wheel Size | 27.5” |
| Fork | Fox 36 Float Factory FIT4, 3-Position w/Low Speed Compression Adjust, Tapered, 15×110mm, E-Bike Optimized, 150mm, Kashima Coated |
| Shock | Fox Float X Factory, 185×55mm, Trunnion Mount, Adjustable LSC w/ 2-Pos. Lever, Kashima Coated |
| Shock Hardware | Top: 54mm Trunnion Mount, Bottom: 22.2×8mm |
| Drive Unit | Bosch Drive Unit Performance CX Generation 4 (85Nm) Cruise (250Watt) |
| Battery | Bosch PowerTube 625 (battery weight 3.6kg) |
| Display | Bosch Kiox |
| Charger | Bosch 4A (2.1h 50% – 4.9h 100%) |
| Brake System | Shimano XT BR-M8120, Hydr. Disc Brake (203/203) |
| Rear Derailleur | Shimano XT RD-M8100-SGS, ShadowPlus, 12-Speed |
| Shifters | Shimano XT SL-M8100-IR, Direct Attach |
| Crankset | e*thirteen Plus Crank, 165mm, 34T |
| Chain Guide | e*thirteen Plus e*spec |
| Cassette | Shimano XT CS-M8100, 10-51T |
| Chain | Shimano CN-M8100 |
| Wheelset | Newmen Evolution SL E.G. 30, 28/28 Spokes, 15×110mm/12×148mm, Tubeless Ready |
| Front Tire | Schwalbe Magic Mary, Super Trail, Addix Soft, Kevlar, 2.4 |
| Rear Tire | Schwalbe Big Betty, Addix Soft, Super Gravity, Tubeless Easy, 2.4 |
| Stem | CUBE Performance Stem E-MTB, 31.8mm |
| Handlebar | Newmen Advanced 318.25, Carbon, 780mm |
| Grips | ACID Disrupt, Soft Compound |
| Seat Post | Fox Transfer Factory 31.6mm, Kashima Coated (XS: 100mm, S: 125mm) |
| Seatclamp | CUBE Screwlock Semi Integrated, 34.9mm |
| Saddle | Natural Fit Venec |
| Headset | ACROS AZF-1035, ICR (Integrated Cable Routing), BlockLock 120°, Top Zero-Stack 1 1/2” (ZS 56mm), Bottom Zero-Stack 1 1/2” (ZS 56mm) |
| Max System Weight | 135kg – The maximum system weight is the maximum total weight of the bike, rider and any luggage combined |
| Quoted Weight | 24.00kg |
Specifications are subject to change without notice
Size Guide
| Frame Size | Minimum Height | Maximum Height |
| X Small (27.5” Wheels) | 152cm (5’0”) | 158cm (5’3”) |
| Small (27.5” Wheels) | 158cm (5’3”) | 168cm (5’6”) |
We have developed our size guide from our selling experience and it may differ from the manufacturers guide. Please note, this is only a guide and if you have any concerns over sizing please get in contact
Geometry
| Frame Size | XS | S |
| Seat Tube | 345 | 395 |
| Top Tub Horizontal | 558.5 | 581.1 |
| Seat Tube Angle | 75.3 | 75.3 |
| Head Tube Angle | 66 | 66 |
| Chain Stays | 448 | 448 |
| Head Tube | 105 | 115 |
| Wheelbase | 1157 | 1181.1 |
| BB-Height To Hub | 15.5 | 15.5 |
| Standover Height | 731.3 | 731.5 |
| Reach | 410 | 430 |
| Stack | 579.5 | 588.7 |
| Crank Length | 165 | 165 |
| Max Tyre Width | 67 | 67 |
Want to compare the size of your current bike to this one? Read our Reach and Stack guide here.
Video
Additional Information
| Manufacturer | Cube |
|---|---|
| RRP | N/A |
